Wuxi Haisheng High Pressure Pump Co., Ltd. HS3P120 — 50 mm / 106 r/min
Haisheng HS3P120 is a larger triplex reciprocating pump family. Its 50 mm plunger selection at 106 r/min pump speed delivers a catalog 74.69 L/min at 34 MPa rated pressure.
HS3P120 triplex high-pressure pumps — official family illustration; supplied configuration must be confirmed.
Published specifications
Manufacturer catalog data
Plunger diameter50 mm
Pump speed106 r/min
Input-shaft reference speed1,480 r/min
Rated pressure34 MPa
Catalog flow74.69 L/min
Catalog power, not confirmed motor rating51 kW
FamilyHS3P120 triplex high-pressure pumps
Product details
The table uses a 1,480 r/min input-shaft reference and presents several pump-speed columns. The chosen 106 r/min column must be matched with the specified transmission; using the input speed as the reciprocating-pump speed would produce an incorrect selection. Other plunger diameters change the pressure and delivery relationship.
The listed power at this point is 51 kW, which is not treated as an installed motor rating. The product-family illustration shows a typical drive arrangement; exact base, coupling and auxiliaries depend on the supplied package. Duty cycle, liquid lubricity and inlet supply should be checked before extending a table point into a continuous-service specification.
SELECTION NOTES
Specify the operating duty
Provide operating pressure, delivery, liquid chemistry and temperature, available inlet pressure and duty cycle. Confirm transmission, motor margin, seals, pulsation control and pressure-relief arrangement.
Published limits may describe different configurations within a series. Confirm that the required operating conditions are valid together.
