Product details
The FJX family develops axial thrust through the impeller blades to circulate liquid in evaporation, concentration and crystallization systems. The catalog identifies salt, caustic and several chemical-processing applications. Material and sealing selection must still match the actual composition, temperature and crystals in the process liquor.
Jinxin describes a cantilever rotor, center-supported casing and back-pull-out service arrangement. Blade angle and speed are selection variables across the family. Packing and cartridge mechanical-seal alternatives are offered, so the sealing arrangement should be specified rather than inferred from the series name.
The listed 15.86 kW is shaft power at the catalog duty, not the motor nameplate rating. The nearby FJX250-5-L row has a different flow and is excluded here. Confirm the chosen impeller, duty curve, motor margin and the support arrangement needed to accommodate pipework forces and thermal expansion in the evaporator loop.
