Jinzhou 500QJW800-50 is a horizontal submersible pump selection listed at 800 m³/h and 50 m head. The catalog pairs this duty with a 185 kW, 380 V motor running at 1,450 r/min.
QJW horizontal submersible pumps — official family illustration; supplied configuration must be confirmed.
Published specifications
Manufacturer catalog data
Flow range800 m³/h
Head range50 m
Motor power185.00 kW
Speed1,450 r/min
Voltage380 V
Catalog current396.09 A
Outlet300 mm
OrientationHorizontal submerged assembly
FamilyQJW horizontal submersible pumps
InstallationHorizontal submerged
Product details
The QJW product page presents horizontal pump-and-motor assemblies for submerged water transfer. The horizontal arrangement needs its own support, intake-clearance and motor-cooling assessment; installation requirements from a vertical well-pump selection should not be assumed to apply.
The performance table contains several frame sizes and operating points. This page uses only the 500QJW800-50 row, with a 300 mm outlet and listed current of 396.09 A. The supplied package can include the pump, motor, discharge connection, waterproof cable and controls; the final scope, cable length and electrical protection must be specified for the installation.
SELECTION NOTES
What to confirm for 500QJW800-50
Provide water level range, intake geometry, water temperature and sediment conditions. Confirm support drawing, motor cooling, cable length, starting method and discharge-pipe loads.
Published limits may describe different configurations within a series. Confirm that the required operating conditions are valid together.
