Product details
The catalog covers frame sizes from 150 to 600 mm, flow from 5 to 2,200 m³/h, head from 5 to 500 m and motor ratings from 3 to 600 kW. These broad ranges belong to different QJW configurations. They are useful for identifying the family’s scope but do not replace the curve and dimensional drawing for a selected unit.
Horizontal installation is the defining application feature. Skysea identifies rivers, lakes, reservoirs, pools and canals as possible locations where water depth can limit a vertical pump. The intake arrangement, minimum operating water level and support layout should be considered together so that the installed unit has suitable inlet conditions.
The product page also names domestic water, mine rescue, agricultural irrigation and fountain service. This listing does not establish that every QJW configuration is suitable for every fluid or installation. Specify water quality, suspended material, power supply and operating cycle before selecting the motor and hydraulic assembly.
